Multifunction Smt Pcb Magazine Loader,High-quality SMT Equipment Provider in China

FOB Reference Price:Get Latest Price
$4,500.00 - $6,500.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Machine Size (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETA
Model Number:
LD-M
Name:
Smt Pcb Magazine Loader
Applicable Components:
0402,0603,0805,1206,QPF,SOP,BGA
Usage:
LED,SMD
Product name:
Smt Magazine Loader
Application:
Pcb Magazine Loader
Warranty:
1 Year
Power Supply:
AC220V 50Hz / AC110V 60Hz
Dimensions(mm):
1550*980*930mm
Component available:
Minimum 01005-38*38*8.5mm (48*48 Optional)
Weight:
200KG
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
Vacuum Wooden Case
Port
Shenzhen
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description

Multifunction Smt Pcb Magazine Loader,High-quality SMT Equipment Provider in China



------Features------

1.  Strong,firm and stable design.

2.  'soft touch' LED control panel or touch screen can be selected.

3. Top&bottom pneumatic clamps to secure magazine rack.

4. No PCB breakage guaranty because of special gas circuit design.

5. Automatical diagnosing fault code display function.

6. Wear-resistant cable and have long service life.

7. Compatible SMEMA interface.













------Specification------



Product Name

SMT Magazine Loader

Model

LD-M

LD-L

LD-LL

LD-XLL

Dimension(mm)

1330*765*1250

1650*845*1250

1800*909*1250

1800*970*1250

PCB Size(mm)

50*50-330*250

50*50-445*330

50*50-530*390

50*50-530*460

Rack Size(mm)

355*320*563

460*400*563

535*460*563

535*530*563

Control System

PLC

Power

Max 300 VA

Transport Height

900±20mm(or Customer Specified)

PCB Direction

L to R or R to L

Communication

SMEMA for Both In & Out

Power Supply

1 PH AC 220V 50/60Hz (Option:110V to 380V)

Weight

 160 Kg 220 Kg 280 Kg 340 Kg
