YAMAHA Chip Mounter YS12F SMT Pick and Place Machine Chip Shooter
YAMAHA SMT LED Pick and Place Machine YS12 YAMAHA SMT LED Pick and Place Machine YS12
Introduction of YAMAHA Pick and Place Machine
The YAMAHA Pick and Place Machine YSM10 is newly developed based on the three "Ones" concept and provides 1) a combination of a mounting speed that is number one in its class, 2) a one-head-solution that does not require replacement, and 3) an integration of three models of the YS12 type into one platform. Simultaneously, the specifications of all three current models of the YAMAHA Pick and Place Machine YS12 series have been integrated into one platform featuring the flexibility and mobility of the compact high-speed modular YS12; the partly simplified version of the compact economy-modular YS12P, and the highly-versatile compact modular YS12F. In addition, pickup and recognition errors are suppressed along with reduced loss in machine stoppage due the integration of the common functionalities of the two high level machines.
■ YAMAHA Pick and Place Machine Speed increases of 25% or more on conventional models and achieving the world's fastest mounting capacity,Based on the ideal concept 1-head solution capable of handling a wide range of components while maintaining high speed without the need for head replacement, we introduced various technologies cultivated from upper model Z:LEX YSM20. By adopting the latest technology such as the same lightweight and compact universal type HM (High-Speed Multi) head as the upper model and the new generation servo system, increases of 25% or more are achieved compared with conventional machines (YS12) in the 1-Beam 1-Head machine class to realize a mounting capacity of the world's fastest at 46,000 CPH (in the Company's optimum conditions) At the same time, it is versatile enough to handle from 03015 (0.3mm x 0.15mm) ultra-small chips to large components of 55mm x 100mm and 15mm in height. In addition,YAMAHA Pick and Place Machine by improving the performance of the scan camera, we have expanded the range of component size compatibility for high-speed mounting from 8mm to 12mm. ■ Scalability for flexibly adjust to production site requirements A range of options are available for selection including the sATS15, an automatic replacement type tray component supply device, the ANC, an auto nozzle station capable of automatically changing nozzles, the multi camera which recognizes components exceeding 6.5mm in height or over 12mm square in size at high speed and high precision.The tape feeder is supported by the electric intelligent feeder SS feeder and ZS feeder used in the YS series. ■ Enhanced functionality to provide for table production Pickup and recognition errors are suppressed along with reduced loss in machine stoppage due the integration of the common functionalities of the top machines of the Z:TA-R YSM40R and the Z:LEX YSM20 with their e-Vision for automatically creating and tracking components data, Smart Recognition for easily creating components data from complicated shapes.
YAMAHA Pick and Place Machine
L 510 x W 460mm - L 50 x W 50mm* Option: Up to L610 mm available
46,000CPH (The Company's optimum conditions)
03015-W 55 x L 100mm (divided recognition for over W 45mm), H: 15mm or less
3-phase AC 200/208/220/240/380/400/416 V ±10% 50/60 Hz
Air supply source
0.45MPa or more, clean and dry state
L 1,254 x W 1,440 x H 1,445mm (excluding protrusions)
