X-Ray Inspection Machine 8200 X ray Detection System Equipment

FOB Reference Price:Get Latest Price
$60,000.00 - $80,000.00 / Sets | 1 Set/Sets (Min. Order)
Usage:
Auto Testing Machine
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETA
Model Number:
8200
Power:
Electronic, 0.5KW
Name:
PCB X-Ray Machine
Product Name:
ETA-8200 PCB X-Ray Machine
Certificate:
CE Certificate
Dimension(W*D*H):
1080*1180*1730 mm
Weight:
1000KG
Voltage:
220V/50Hz
Application:
BGA, PCB, CSP, LED, Flip Chip, Semiconductor, etc.
Function:
SMT PCB X-Ray
Warranty:
1 Year
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden Case
Port
Shenzhen
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description
Product Description

X-Ray Inspection Machine 8200 X ray Detection System Equipment


Products introduction:


ETA-8200 is designed to provide high resolution x-ray imaging primarily for the electronics industry. This versatile system is effective for many applications within the PCB manufacturing process. This includes BGA, CSP, QFN, Flip Chip, COB and the wide range of SMT components. The ETA-8200 is a powerful support tool for process development, process monitoring and refinement of the rework operation. Supported by a powerful and easy to use software interface, the ETA-8200 is capable of addressing small and large volume factory requirements. (Contact us for details)

Features:


●100KV 5μm X-ray tube, image intensifier with 2 mega pixels CCD camera.
●Multi-function workstation with ±60° "Arc" motion and X-Y multi-axis movement.
●X-ray tube & detector automatic lifting and descending, with convenient target point positioning system.
●Multi-function DXI image processing system, programmable detection.
●Max. loading area 510mm*420mm , max. detection area 435*385mm,with 1200X System Magnification.

Applications:


BGA , CSP , LED , Flip Chip , Semiconductor, Battery Industry , Small Metal Casting, Electronic Connector Module,
Aerospace Components , Photovoltaic Industry, Other Special Industries.





Specification
Model
BGA X-Ray 8200
Dimension
W1080 X D1180 X H1730 mm
Total Power
0.5KW
Voltage
220VC/50Hz
System Magnification
1200X
Weight
1000kg


X-Ray Tube
Type
Closed
Max Voltage
100kv
Max Current
200μA
Motion
1500mm


Work Station
Standard Dimension
420*510mm
Detection Area
385*435mm
Tilting Angle
±60°
Max Load Weight
8 kg
Company Information
Why Choose Us



ETAis the leading SMT factory solution provider in China ,offering professional SMT factory building advice and service.We have 22 years experience about SMT factories,offering full solution for global clients with our advantaged sources in China.Our core technology team members are all from Foxconn, Huawei, Siemens and other companies,we not only provide a full set of equipments, we also provide full smt technical support and services,Besides we give customers more reasonable and professional suggestions.We have already helped many customers to establish factories in LED, TV, Phone, DVB, EMS and other filed around the world ,we are worthy of trust!

Successful Experience:
 We have been helping customers to build a lot of new factories around the world.
Training more than 500 experts and technician for customers.
Became the most reliable Chinese partner for you.



Our Customer

ETA Engineers installedin Vietnam

ETA Engineers installedin Russia

ETA Engineers installedin Iran







Our team

Exhibition







Certifications

FAQ
1.Are you a trade company or a manufacturer?
=>OEM & ODM service are available.

2.What is your delivery date?
=>The delivery date is about 35 days after receipt of payment.

3.What is your payment terms?
=>30% deposit in advance and 70% balance before shipment.

4.What your main customers?
=>Huawei,Foxconn,Vtech,Sumida,Kemet,Vishay,Bosch,Canon.

Our Service

Pre-Consultation: provides professional SMT solutions for the full line.
Factory Warranty: One-year warranty factory service.
Installation: On-site installation and commissioning, to ensure smooth production.
Technical Training: provides professional training from Level 1 to Level 3.
Technical Support: provides 7 * 24 technical support.
Software Upgrade: offers lifetime free software upgrades for all products

Packing & Delivery
Packing method:
Standard wood package ,we do sure the goods won't be breakdown in transit

Shipping way :
By air ,for sample and small package ,international             express like DHL,UPS,EMS....
By sea, for large package and quantity;
Other ways as customer requested;

Delivery time:
  30 Days
