Samsung Sm482 SMD Chip Mounter SMT Pick And Place Machine Chip Mounting Machine

FOB Reference Price:Get Latest Price
$75,000.00 - $132,000.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 Negotiable
Customization:
as per customer's request (Min. Order: 1 Sets)
Customized logo (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
South Korea
Brand Name:
SamSung
Model Number:
S481
Feeder inputs:
Electric and Pneumatic
Lane:
Single and Dual
Placement speed:
78,,000CPH
Component Registration:
Easy
conveyor specification:
standard
mounting process:
smart
compatibility:
Extensive
centering height:
automatically adjustable
component range:
Wide
head replacment:
no need
Supply Ability
Supply Ability:
80 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden package, container
Port
HK
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 To be negotiated
Video Description
Product Description

Samsung Sm482 SMD Chip Mounter SMT Pick And Place Machine Chip Mounting Machine

------Specification------

As a high performance chip shooter that applies two gantries equipped with 10 spindles per head as well as new flying vision, the
SM471 realizes a chip mounting speed of 78,000 CPH, the highest in the world among chip shooters of the same class. In addition,
it is applicable to 0402 chips to the largest .
Model
SM471PLUS
SM481PLUS
SM482PLUS
Numbers of Spindles
10 Spindles × 2 Gantry
10 Spindles × 1 Gantry
6 Spindles × 1 Gantry
Placement Speed
78000CPH(Optimum)
40000CPH(Optimum)
30000CPH(Optimum)
Placement Accuracy
±50μm@μ±3σ
±30μm@μ±3σ
±30μm@μ±3σ
Applicable Parts
0402 ~ 14mm(H 12mm)
0402 ~ 42mm(H15mm)
0402 ~ 55mm(H 15mm)
Applicable PCB
Max. 510(L) x 460(W)(Standard)
Max. 460(L) x400(W)(Standard)
Max. 460(L) x400(W)(Standard)
Max. 610(L) x 460(W)(Option)
Max. 1500(L) x 460(W)(Option)
Max. 1200(L) x 510(W)(Option)
Dimension(mm)
1650×1690×1458
1650×1680×1530
1650×1680×1458

Features:

1. 78,000 CPH(Optimum)
2. 2 Gantry x 10 Spindles/Head
3. Applicable Parts : 0402 ~ 14mm(H12mm)
4. Electrically Driven High Speed and High Precision Feeder
- Allows mixed use with an SM pneumatically driven feeder
SMART Feeder
- The world's first feeder equipped with Auto Splicing and Auto Loading functions
Our Company

ETA is the leading manufacturer for smt machines and solution with 23 years' experience in China. And we are aslo the only Chinese SMT supplier for Huawei factory in China.

Successful Experience:

Eta's customer in 35 countries around the world
※ We have been helping customers to build a lot of new factories around the world.
※ Training more than 500 experts and technician for customers.
※ Became the most reliable Chinese partner for you.

Certifications
Exhibition
Packing & Delivery

Packing method:
※ Standard wooden package

Shipping Way:
※ By air, for sample and small package,international express like DHL, UPS, EMS...
※ By sea, for large package and quantity;
※ Other ways as customer requested.

Delivery Time:
※ 35 Days

FAQ

1.Are you a trade company or a manufacturer?
=》OEM & ODM service are available.

2.What is your delivery date?
=》The delivery date is about 35 days after receipt of payment.

3.What is your payment terms?
=》30% deposit in advance and 70% balance before shipment.

4.What your main customers?
=》Huawei,Foxconn,Vtech,Sumida,Kemet,Vishay,Bosch,Canon.
